Teledyne FLIR, part of Teledyne Technologies Incorporated, today launched a comprehensive online developer support series for the new Boson®+ thermal camera and Hadron™ 640R dual camera module. The program includes integration support videos and additional online content, offering tips and documentation to help reduce risk while simplifying thermal product development in defense, industrial, and emerging use cases. “Teledyne FLIR provides data packages like comprehensive user guides, drawings, and app notes as well as GUIs, SDKs, and development kits to support the integration of our thermal camera modules in drones, handhelds, security products, and more,” said Dan Walker, vice president, product management, Teledyne FLIR.

“The integration support series is a key differentiator for Teledyne FLIR where we provide online support to enable our customers to start developing with our hardware, software, and tools immediately.”

Teledyne FLIR offers the most comprehensive development-to-production support in the industry. The new video and download series includes guidance on setting up radiometry, tuning, lens calibration, and software and MIPI integration for Boson+. Step-by-step instructions get integrators started interfacing the Hadron 640R with cutting-edge Qualcomm and NVIDIA embedded systems. Additional content will be added as available to continue to support integrators get to market faster. Plug-and-Play Integration With a thermal sensitivity of 20 millikelvin (mK), Boson+ is the most sensitive longwave infrared (LWIR) camera line in the market and is a drop-in upgrade for the widely deployed Boson thermal camera module. Hadron 640R pairs a performance-leading 640x512 resolution radiometric Boson® thermal camera with a 64MP visible camera in a single easy-to-integrate module.

Designed to optimize size, weight, and power (SWaP) and manufactured in the USA, the Boson+ and Hadron 640R are ideal for integration in unmanned ground vehicles (UGV), unmanned aircraft systems (UAS), automotive, wearables, security applications, handhelds, and thermal sights. Full Support for the Entire Product Lifecycle The Teledyne FLIR advantage reduces cost and risk from development to production to product support. Designed for integrators and with industry-leading warranties, the SWaP and cost-optimized highperformance thermal camera modules are AI-compatible and can include factory-integrated lenses to speed development. Integration is made easy with application notes, videos, tools, and support from the applications team to enable optimized camera performance. With more than 40 years of US-based, full-rate manufacturing experience, Teledyne FLIR is the low-risk supply-chain partner. To learn more about the integration series, please visit www.flir.com/time.

What challenges are machine builders and switch-gear system manufacturers facing in today’s global markets? How can the right course be set for efficient engineering at an early stage in the game? This year’s Eplan L!ve 2023 event on 21 June 2023 is providing distilled answers, highlights from the new version of the software, and demonstrates how Eplan shepherds its customers on every step of their journey from engineering to manufacturing. And it does this from precisely the point where their clients find themselves in their processes. Companies such as Harro Höfliger, Kratos Industries and Sany will present some of their best practices on the world market and provide insights into their workflow practices and engineering methods that allow maximum consistency and efficiency.

Monheim, Germany – What are the current trends for engineering on the global market? How can topics including the energy transition, networking ecosystems, the skilled-worker shortage, and the digital transformation be implemented in the best way possible as regards engineering? Solutions provider Eplan will be providing focused answers to these question during its new online event “Eplan L!ve” on 21 June 2023.

High-profile players in machine building such as Harro Höfliger from Germany and Sany from China will be providing input and insights into their own well-tested methods and processes. Kratos Industries, a control cabinet manufac-turer based in the US, will be sharing its experiences with 3D control cabinet designs, including fully automated manufacturing using the Wire Terminal WT and Perforex Machining Centre, both made by Rittal. Informative and international “With this year’s new online event, we’re focusing on the challenges our customers are facing, particularly in the machine building and switchgear system manufacturing sectors,” says Eplan Vice President Customer Journey Jan Fleming. “Our goal is sharing practical experience – both from the manufacturer’s and the customer’s points of view. Along with market trends and customer’s own best practices, this distilled programme will also be presenting an initial preview of the upcoming version of Eplan. If we all share these experiences with each other, learn from one another and remain actively engaged in dialogue, we will ensure the highest efficiency for engineering in the future.”

A look behind the scenes: The new Eplan Platform After a first preview at the Hannover Messe, attendees will now also be able to become familiar with the Eplan Platform 2024. New mathematical calculation functions, greater ease of use in terminal management, and unprecedented possibilities for navigating through the 3D model of a control cabinet are just a few of the new features that users can look forward to. This all also helps make creating the digital twin in Eplan Pro Panel even easier. Another new function: When it comes to machine cabling in conjunction with Eplan Harness proD, spare wires can be connected in no time at all with just a click. Register free of charge at: www.eplan-software-com/live

Enerpac announces a new Ultra-Flat hydraulic cylinder series for those projects with small working space, starting at just 2,8 cm, but large lifting requirements up to 1000 ton. The CULP-Series with lifting capacity 10 – 50 ton, and CUSP-Series 10 – 1000 ton, are designed for applications where high lifting forces are needed in confined spaces.

With a 700 bar max operating pressure, the Ultra-Flat cylinders provide a 7 – 17 mm stroke, and are designed to withstand up to 4% side load at full lifting capacity. The CUSP-Series has an integrated tilting function up to 4 degrees, and a 6 – 10mm tilted stroke.

Safety is critical to all Enerpac products. CULP Ultra-Flat hydraulic cylinders are equipped with an internal stop ring that prevents the plunger from accidentally dropping at the end of its stroke. CUSP Cylinders have a “Red Line” as visual indicator to the operator when the maximum stroke has been reached. The CUSP-Series’ tilting plunger can be adjusted enabling equal distribution of load over its full surface. Even at maximum tilted position, most models will have a straight lifting stroke of 10 mm.


All Enerpac cylinders are built to last. In addition to low maintenance requirements, the Ultra-Flat hydraulic cylinders feature a nitro carburizing surface treatment providing greater load and wear resistance, as well as, corrosion protection in the harshest working conditions.

The CULP-Series and CUSP-Series Ultra-Flat hydraulic cylinders can be used with Enerpac hydraulic pumps - available in over 1000 different configurations – whatever the application’s requirements for speed, control, intermittent or heavy duty.

For more information on Enerpac Ultra-Flat hydraulic cylinders, visit: www.enerpac.com

Photo caption 1: Enerpac Ultra-Flat Cylinders for Big Lifts in Small Spaces.

Photo caption 2: The Enerpac CUSP-Series Ultra-Flat hydraulic cylinders.

This article can also be found in issue below.

Heat treatment processes are a crucial component of many manufacturing processes, and thermal loop solutions have become increasingly popular for achieving improved temperature control and consistent outcomes. But many OEMs are missing opportunities where thermal loop solutions offer more than just greater control. In this article, Peter Sherwin, global business development manager for heat treatment at supplier Watlow, explores the possibilities of thermal loop solutions.

A thermal loop solution is a closed loop system with several essential components, including an electrical power supply, power controller, heating element, temperature sensor and process controller. The electrical power supply provides the energy needed for heating, the power controller regulates the power output to the heating element, the heating element heats the material, and the temperature sensor measures the temperature. Finally, the process controller adjusts the power output to maintain the desired temperature for the specified duration, providing better temperature control and consistent outcomes.

Performance benefits

Heat treatment thermal loop solutions offer several advantages over traditional heat treatment methods, including improved temperature control and increased efficiency. The thermal loop system provides precise temperature control, enabling faster heating and cooling and optimized soak times. In addition, the complete design of modern thermal loop solutions includes energy-efficient heating and overall ease of use.

Thermal loop solutions can also be integrated with Industry 4.0 frameworks and data management systems to provide real-time information on performance. Combining AI and machine learning algorithms can also provide additional performance benefits, such as the ability to analyze data and identify patterns for further optimization.

The effectiveness of heat treatment thermal loop solutions can be measured using metrics such as overall equipment effectiveness (OEE). OEE combines metrics for availability, performance, and quality to provide a comprehensive view of the efficiency of a manufacturing process. By tracking OEE and contextual data, organizations can evaluate the effectiveness of their heat treatment thermal loop solutions and make informed decisions about optimizing their operations.

Supporting sustainability

Heat treatment thermal loop solutions provide several sustainability benefits, including reduced energy consumption and waste. The power controller regulates the power output to minimize energy waste, and the possible integration with renewable energy sources provides a complete power solution that spans from element design to recycling. The thermal loop solutions, in combination with insulation design and materials, provide energy-efficient solutions that contribute to sustainability and reduce the environmental impact of heat treatment processes.

When discussing these systems in the context of greenhouse gas emissions and the environmental impact, it's essential to consider Scopes 1 (direct emissions), 2 (indirect emissions from energy), and 3 (other indirect emissions), as well as the less common Scope 4 (avoided emissions).

At the component level, energy savings can be realized using current technology. Advanced Selective Catalytic Reduction (SCRs) provide predictive load management functions and hybrid firing algorithms contribute to sustainability by optimizing the energy usage of heat treatment processes. These SCRs offer real-time monitoring and control of energy consumption, while predictive load management systems use specific algorithms to manage peak power loads and adjust to optimize for local conditions such as load shedding or load sharing.

Adaptive thermal system (ATS) solutions are the next frontier of thermal loop solutions. Watlow has decades of experience with to help engineers and designers to incorporate ATS technology into a variety of industrial processes and products.

ATS, which combines sensing, heating and control technologies, represents a different and more innovative approach to controlling thermal performance for complex systems, and provides a merged design between heater and control systems.

Regulatory compliance

NADCAP, the National Aerospace and Defense Contractors Accreditation Program, is an industry-driven program that provides accreditation for special processes in the aerospace and defense industries. Heat treatment is considered a "special process" under NADCAP because it has specific characteristics crucial to aerospace and defense components. These characteristics include process sensitivity, limited traceability, critical performance requirements and potential risk.

NADCAP heat treatment accreditation ensures suppliers meet industry standards and best practices for heat treatment processes. The accreditation process includes audits, thorough documentation, and ongoing process control monitoring to maintain high quality, safety, and performance levels.

The aerospace industry's AMS2750TMG pyrometry specification and the automotive industry's CQI-9 Issue 4 regulations are crucial for ensuring consistent and high-quality heat-treated components. Adherence to these regulations is essential for meeting the stringent quality requirements of the aerospace and automotive industries and other industries with demanding specifications.

Continuous improvement is also emphasized by both AMS2750G and CQI-9 Issue 4, requiring manufacturers to establish a system for monitoring, measuring and analyzing the performance of their heat treatment systems. This development enables manufacturers to identify areas for improvement and implement corrective actions, ensuring that heat-treating processes are continuously improving and meeting the necessary performance and safety standards.

By integrating these regulations into a precision control loop, heat treatment thermal loop solutions can provide the necessary level of control and ensure compliance with AMS2750G and CQI-9 Issue 4, leading to the production of high-quality, heat-treated components that meet the performance required and safety standards.

Heat treatment thermal loop solutions provide several benefits over traditional heat treatment methods, including improved temperature control, increased efficiency, and improved sustainability outcomes. The integration with Industry 4.0 and data management systems, as well as the use of OEE metrics, further help enhance the performance of heat treatment processes. As Industry 4.0 digital transformation continues to evolve, heat treatment thermal loop solutions will play an increasingly important role in the future of heat treatment.

www.watlow.com

This article can also be found in the issue below.

Chemical hazards in industries can cause serious harm to workers and the environment. To prevent these hazards, it is essential to have visual warnings and inspection recording in place. Visual warnings, such as labels, signs, and placards, can alert workers to the presence of hazardous chemicals and inform them of the proper precautions to take.

The purpose of the Chemtag is in case there is an accident or incident where the chemicals are stored or with a person coming into contact. It pulls the pertinent information off the COSHH safety data sheets and makes it immediately available for first aid or medical purposes.

1 = what fire extinguisher is required

2 = what's the immediate first aid action

3 = what's the immediate spill response

So the fire brigade know what they're dealing with and the ambulance can take the card, take the person and away they go.

Hazardous substances:

• Substances used directly in work activities such as adhesives, paints and cleaning agents
• Substances generated during work activities such as fumes from soldering and welding
• Naturally occurring substances such as grain dust
• Biological agents such as bacteria and other micro-organisms

The control of substances hazardous to health (COSHH) regulations 2002 specifically requires employers to:

• Assess the risks to health from hazardous substances used in or created by your workplace activities. Decide what precautions are needed. If you have five or more employees you must make and keep a record of the main findings of the assessment, either in writing or on computer
• Prevent or adequately control exposure
• Ensure that control systems used are maintained properly and that safety procedures are followed
• Monitor the exposure of employees to hazardous substances
• Carry out appropriate health surveillance where your assessment has shown this is necessary or where COSHH sets specific requirements
• Prepare plans and procedures to deal with accidents, incidents and emergencies involving hazardous substances
• Ensure employees have suitable and sufficient information, instruction, training and supervision

Which Scafftag systems can help you?

• Permit Wallets: Provides ultimate protection and ease of viewing of permits / documents at the point of use.
• Chemical hazard inspection tagging systems: the pertinent information off the COSHH safety data sheets and makes it immediately available for first aid or medical purposes
• SafeTrak Inspection Software: Recording details of inspections and testing results

Find out more about Visual Tagging Systems >>

Scafftag – A Brady Business

This email address is being protected from spambots. You need JavaScript enabled to view it.

Tel 0845 089 4060

www.scafftag.co.uk

• Schaeffler honours 19 suppliers with the Schaeffler Supplier Award
• Close partnerships with suppliers are key to long-term corporate success
• Schaeffler Supplier Day: focus on sustainability and digitisation in the supply chain

Birmingham, UK | May 25, 2023 | The global automotive and industrial supplier Schaeffler presented 19 of its suppliers with the Schaeffler Supplier Award at the Supplier Day in Herzogenaurach, Germany, in honour of their exceptional performance. Georg F.W. Schaeffler, Family Shareholder and Chairman of the Supervisory Board of Schaeffler AG, and Klaus Rosenfeld, CEO of Schaeffler AG, presented the awards in the five categories of Innovation, Sustainability, Cost Efficiency, Quality, and Supply Chain before an audience of more than 450 guests.

Andreas Schick, Chief Operating Officer of Schaeffler AG, said: “A close, trusting relationship with our suppliers is crucial to Schaeffler. Given the enormous challenges we are currently facing in global supply chains, close partnerships are now more important than ever and are key to long-term corporate success.”

The key topics of digitisation and sustainability in the supply chain occupied centre stage at the Schaeffler Supplier Day. Andreas Schick: “Digitisation offers considerable potential for new products and solutions, and Schaeffler is actively driving the company’s transformation forward with digital solutions along the entire supply chain. In conjunction with our suppliers, we will make joint use of the opportunities that digitisation presents to make value creation more agile, efficient, and ultimately, even more sustainable.”

The strategic importance of digitisation to Schaeffler is also reflected in all of the supplier awards in the “Innovation” category. The award was presented to suppliers for digital solutions developed in areas such as Industry 4.0, or for the joint development of online service portals. With awards in the “Sustainability” category, Schaeffler honours suppliers who support the corporate goal of achieving climate neutrality by 2040 by focusing extensively on using raw materials efficiently, recycling production waste, or generating electricity from renewable energies. The Schaeffler Supplier Award in the “Supply Chain” category is presented to top suppliers for excellent delivery reliability and particularly resilient delivery chains, while the awards in the “Quality” category honour outstanding quality performance. The awards in the “Value” category are presented by Schaeffler to honour strong partnerships, which are particularly important for the company’s competitiveness worldwide.

The recipients of the 2023 Schaeffler Supplier Award:

• RPK S. Coop., Spain
• FAIST Mekatronic, Romania
• POSCO, South Korea
• Shandong Golden Empire Precision Machinery Tech., China
• Trafilspec ITS S.p.A., Italy
• Draxton, Spain
• Edmund G. Friedrich & Co. GmbH, Germany
• Imperial Logistics International B.V. & Co. KG, Germany
• Kentpar Otomotiv Yedek Parça AŞ, Turkey
• Delux Bearings Pvt. Ltd., India
• hmmh multimediahaus AG, Germany
• Ravi Technoforge Pvt. Ltd., India
• UMBRAGROUP S.p.A., Italy
• NHB BALL & ROLLER LTD, India
• Statkraft Markets GmbH, Germany
• Hwacheon Machine Tools Co., Ltd, South Korea
• Mitsubishi Materials Corporation, Japan
• Tyrolit – Schleifmittelwerke Swarovski AG & Co K.G, Austria
• Siemens AG Digital Industries, Germany

www.schaeffler.com

The deadline is rapidly approachingto investin a team of fast-rising innovators, who have already completed over 100 installations worldwide of their energy-saving wastewateraeration solutions.

Via Crowdcube, but only until June 10th, shares can be purchased in Mapal; a thriving business (established 2008) that has seen a significant increase in demand for its aeration technologies, which do notrequire a levelled floor and, importantly, cause no unwanted downtimebecause they canbe installed and maintained while the plant is operating.

Ilan Diamond, Mapal’s Chairman/Director, said: “With our systemsproving up to 50-60%moreefficient than traditionalmechanicalsurfaceaeration– and with nomovingpartsinthewater, there is huge potentialgrowth for what we offer.”

He added: “This investment opportunity will provide general working capital, enabling us to accelerate our healthy growth by furtherdeveloping our sales and marketing teams. We will also be able to fund a pre-sale trial (rental) fleet and continueour research & development into ammonia removal in aerated lagoons with fixed bio-media combined into our Mapal FFBA(Floating Fine Bubble Aeration) system.”

Some recent aeration methods partly address the higherthan ever energy (and maintenance) costs of conventional surface treatment, but requiring specific conditions, can also prove expensive as a new-build, with problematicalprocess interruption for upgrades. But from Israel, the UK, Brazil, Australia and across Africa, Mapal’s custom-made systemshave successfully supersededthese drawbacksfor municipal and industrial wastewatertreatment plants of numerous types, shapes and sizes.

Mapal’s Ilan Diamond, continued: “Our innovative and proven technology, togetherwithour strong customersupport, should see our sales grow from US$ 0.65 millionlast year to US$ 2.1this year, then US$ 3.0 million in 2025. We are very excited about the future for delivering the benefits of our equipment to theglobal wastewater industry.”

More details about investing in Mapal via Crowdcube* can be found at:

www.mapal-ge.com

Thorite has been awarded Pro-Partner status by Piab Group, consolidating its position as the leading UK distribution partner for the global brand’s vacuum automation products.

The enhanced partnership recognises Thorite’s expertise in the sales and servicing of vacuum pumps, ejectors and accessories. It will strengthen collaboration between the Bradford-based company and Piab, which is headquartered in Sweden, to stimulate growth for both companies.

Thorite is the only company in the UK to have achieved Tier B partnership status with Piab – the highest in its business category – which is based on success in sales revenue, growth ambition, marketing support and workforce education.

Thorite’s Sales Director, Mark Yates, said: “We place enormous value on this recognition from our key suppliers.

“Vacuum is a key area identified for growth as part of our future development and our investment in training and education on its market applications is delivering some great opportunities.

“The award of Pro-Partner status cements our relationship with the Piab brand and will deliver benefits for both companies and, most importantly, for our customers.”

www.Thorite.co.uk

We have seen a lot of development through the years and are grateful for the opportunity we have been given by our customers to do so!

We want to celebrate with you - by giving away some beer for you to enjoy.

So this summer you really can sit back, relax and enjoy a drink on us!

For a chance to win one of 5 crates of beer, all you need to do is register via the link below and fill out the questionnaire. You will need to answer the questions correctly – so hopefullyyou’ve been paying attention!

Good luck and thank you for all the support we have received in the past 40 years!

Enter here: https://www.testo.com/en-UK/summer-giveaway

AS-Schneider will rename its digital nameplate Digital Product Pass (DPP) to Digital Valve Plate (DVP). With this, the valve specialist draws a clear line between its solution for marking valves and manifolds and an initiative of the EU, which also operates under the name Digital Product Pass and is becoming increasingly important in the industry. Now, mix-ups are excluded and both solutions can be further developed in parallel.
Products in the process industry are usually delivered with a large number of technical documents. Depending on the project scope, hundreds of printed pages of drawings, material certificates, testing documents as well as maintenance and servicing information are generated. In order to advance the digitalization of mechanical components and to take a step towards Industry 4.0, AS-Schneider has already introduced its digital nameplate based on DIN SPEC 91406 under the name "Digital Product Pass" in 2019.
What was not known at the time, however, was that the European Commission was working on a Digital Product Pass of the same name as part of the Sustainable Product Strategy. In recent months, this EU Digital Product Pass has increasingly established itself as a fixed term in the industry, according to AS-Schneider.
In order to create clarity and avoid confusion, the valve specialist finally decided to rename its solution. DPP now officially becomes Digital Valve Plate (DVP). The name was created in reference to the administration shell as well as the Smart Valve introduced last year called

Product information

"Digital Valve Kit". Digital Name Plate als auch dem letzten Jahr vorgestellten Smart Valve namens „Digital Valve Kit“. "In this way, we are paving the way for both essential solutions: the implementation of the EU's Digital Product Pass and the expansion of AS-Schneider's Digital Valve Plate to provide relevant product information," describes Thomas Weisschuh, Head of Product Management & Innovation at AS- Schneider.

www.as-schneider.com
